Analog/digital converter (ADC) UM0306
472/519
19.13.2 ADC control register 1 (ADC_CR1)
Address offset: 04h
Reset value: 0000 0000h
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
AWD
EN
AWD
ENJ
Reserved DUALMOD[3:0]
rw rw rw rw rw rw
1514131211109876543210
DISCNUM[2:0]
DISC
ENJ
DISC
EN
JAUT
O
AWD
SGL
SCAN
JEOC
IE
AWDIE EOCIE AWDCH[4:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:24 Reserved, must be kept cleared.
Bit 23
AWDEN: Analog watchdog enable on regular channels
This bit is set/reset by software.
0: Analog watchdog disabled on regular channels
1: Analog watchdog enabled on regular channels
Bit 22
JAWDEN: Analog watchdog enable on injected channels
This bit is set/reset by software.
0: Analog watchdog disabled on injected channels
1: Analog watchdog enabled on injected channels
Bits 21:20 Reserved, must be kept cleared.
Bits 19:16
DUALMOD[3:0]: Dual mode selection
These bits are written by software to select the operating mode.
0000: Independent mode.
0001: Combined regular simultaneous + injected simultaneous mode
0010: Combined regular simultaneous + alternate trigger mode
0011: Combined injected simultaneous + fast interleaved mode
0100: Combined injected simultaneous + slow Interleaved mode
0101: Injected simultaneous mode only
0110: Regular simultaneous mode only
0111: Fast interleaved mode only
1000: Slow interleaved mode only
1001: Alternate trigger mode only
Notes:
–These bits are reserved in ADC2.
–In dual mode, a change of channel configuration generates a restart that can
produce a loss of synchronization. It is recommended to disable dual mode
before any configuration change.
