5 Setup Data
Setup2 Editor
Yarn data
Yarn data The yarn data are necessary for the calculation of the yarn consumption.
Further information:
 Helpers for Input [311]
 File tools [317]
 Table Tools [316]
 Setup Data [303]
 Overview of the Setup2 Editor
of the CMS [
309]
 Comparing Setup1 to Setup2 [305]
Explanation
"Wheel"
right device: Select measuring wheel (n=1
to 8).
left device: Select measuring wheel (n=9 to 16).
"Y" Select the yarn carrier (1A to 8D) working with this measuring
wheel.
"Yarn Quality"
for yarn
disposition only
"Yarn"
A maximum of 5 yarns can be threaded into one measuring wheel.
The yarn data is entered in a separate line for each yarn.
"Yarn Quality"
Example:
Enter 28 here
"Number of Yarn Threads"
Enter the number of individual threads.
Example:
Enter 2 here
"Number of Threads "
Enter the number of threads per yarn carrier here
NM; TEX; DTEX; NE/C; NE/W; DEN
Select unit for the yarn thickness.
Enter NM here
"Yarn ID"
Yarn ID or comment
