Toyota 22R-E - EGR Valve Inspection

To Next Page

To Previous Page

1. REMOVE EGR VALVE

Check the valve for sticking and heavy carbon de–

posits. If a problem is found, replace it.

2. INSTALL EGR VALVE WITH NEW GASKET

EGR VALVE INSPECTION

–ENGINE EMISSION CONTROL SYSTEMS

EG1–91
