3. REMOVE COLD START INJECTOR
(a) Put a suitable container or shop towel under the cold
star injector pipe.
(b) Remove the union bolts and four gaskets, and remove
the cold start injector pipe.
HINT: Slowly loosen the union bolt.
(c) Remove the two bolts and cold start injector with the
gasket.
ON–VEHICLE INSPECTION
MEASURE RESISTANCE OF COLD START INJECTOR
(a) Disconnect the cold start injector connector.
(b) Using ohmmeter, check the resistance of the injector.
Resistance: 2 –4 
(c) Connect the cold start injector connector.
COLD START INJECTOR REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE TERMINAL
OF BATTERY
2. DISCONNECT COLD START INJECTOR CONNEC–
TOR
COLD START INJECTOR
–ENGINE MFI SYSTEM
EG1–183
