4. INSTALL FUEL TANK
NOTICE:
• Tighten the pipe and flare nut type hose to the
specified torque.
• Push in the pipe and insert–type hose to the spe–
cified position, and install the clip to the specified
location.
• If reusing the hose, reinstall the clip at the original
location.
5. REFILL WITH FUEL
3. INSTALL FUEL PUMP BRACKET
(a) Place the bracket with a new gasket on the fuel tank.
(b) Install and tighten the seven bolts.
Torque: 3.9 N–m (40 kgf–cm, 34 in.–lbf)
–ENGINE MFI SYSTEM
EG2–207
