Toyota 22R-E - Inspect Throttle Body; Inspect Throttle Position Sensor

.
2. INSPECT THROTTLE POSITION SENSOR
Check the resistance between the terminals.
• Unplug the connector from the sensor.
Insert a thickness gauge between the throttle stop
screw and stop lever.
• Using an ohmmeter, check the resistance between
each terminal.
ON–VEHICLE INSPECTION
1. INSPECT THROTTLE BODY
(a) Check that the throttle linkage moves smoothly.
(b) Check the vacuum at each port.
• Start the engine.
• Check the vacuum with your finger.
THROTTLE BODY
At 3,500 rpm
No vacuum
No vacuum
No vacuum
Port name
At idling
Vacuum
Vacuum
Vacuum
–ENGINE MFI SYSTEM
EG1–197
