EGR GAS TEMP. SENSOR INSPECTION
MEASURE RESISTANCE OF EGR GAS TEMP. SENSOR
Using an ohmmeter, measure the resistance between
both terminals.
Resistance:
69–89 k at 50C (122F)
11–15 k at 100C (212F)
2 –4 k at 150C (302F)
If the resistance is not as specified, replace the
sensor.
EGR GAS TEMPERATURE SENSOR
–ENGINE MFI SYSTEM
EG1–214
