4. INSPECT HIGH–TENSION CORD RESISTANCE
Using an ohmmeter, measure the resistance without
disconnecting the distributor cap.
Maximum resistance:
25 kQ per cord
If the resistance is greater than maximum, check the
terminals. If any defect has been found, replace the
high–tension cord and/or distributor cap.
HIGH–TENSION CORDS INSPECTION
1. DISCONNECT HIGH–TENSION CORDS FROM
SPARK PLUGS
Disconnect the high – tension cords at the rubber
boot. Do not pull on the curds.
NOTICE: Pulling on or bending the cords may damage the
conductor inside.
2. REMOVE DISTRIBUTOR CAP WITH
HIGH–TENSION CORDS
3. INSPECT HIGH–TENSION CORD TERMINALS
Check the terminals for corrosion, breaks or distor–
tion. Replace cords as required.
5. REINSTALL DISTRIBUTOR CAP AND
HIGH–TENSION CORDS
6. RECONNECT HIGH–TENSION CORDS TO SPARK
PLUGS
–ENGINE ENGINE MECHANICAL
EG2–15
