Toyota 22R-E - Remove No.2 and No.3 Fuel Pipes; Remove No.4 Timing Belt Cover; Remove No.2 Idler Pulley

19. REMOVE ENGINE WIRE
(a) Disconnect the following:
• Knock sensor connector
• Cold start injector time switch connector
• ECT sensor connector
• ECT sender gauge connector
• No.1 ECT switch connector
• RH ground strap from No.3 camshaft bearing cap
• Injector connectors
20. REMOVE NO.2 AND NO.3 FUEL PIPES
(a) Disconnect the vacuum hose from the TVV.
(b) Remove the four union bolts, eight gaskets, No.2 and
No.3 fuel pipes.
21. REMOVE NO.4 TIMING BELT COVER
Remove the four bolts and timing belt cover.
22. REMOVE NO.2 IDLER PULLEY
Remove the four bolts and idler pulley.
(b) Remove the two bolts and engine wire.
–ENGINE ENGINE MECHANICAL
EG2–56
