13. RECONNECT– HIGH –TENSION CORDS TO SPARK
PLUGS
9. INSTILL CYLINDER HEAD COVERS
(See step 7 on page EG2–80)
10. INSTALL ENGINE WIRE
Install the engine wire with the two bolts.
12. INSTALL SPARK PLUGS
Using a 16 mm plug wrench, install the six spark
plugs.
Torque: 18 N–m (18a kgf–cm, 13 ft–lbf)
11. INSTALL AIR INTAKE CHAMBER
(See step 24 on pages EG2–84 to 87)
–ENGINE ENGINE MECHANICAL
EG2–24
