5. DISCONNECT VACUUM SENSING HOSE
6. DISCONNECT FUEL RETURN HOSE
(a) Place a suitable container or shop towel under the fuel
pressure regulator.
(b) Disconnect the fuel return hose from the fuel pressure
regulator.
3. DISCONNECT FOLLOWING CABLES:
(a) (w/ Cruise control)
Actuator cable with bracket
(b) Accelerator cable
(c) (A/T)
Throttle cable
4. DISCONNECT AIR CLEANER HOSE
7. REMOVE AIR INTAKE CHAMBER
(a) Disconnect the throttle position sensor connector.
(b) Disconnect the canister vacuum hose from the
throttle body.
(d) Disconnect the No.4 water by–pass hose from the
union of the intake manifold.
(c) Disconnect the PCV hose from the union.
–ENGINE MFI SYSTEM
EG2–213
