If not within the specification, check the fuel pump,
pressure regulator and/or injectors.
(t) After checking fuel pressure, disconnect the battery
ground strap and carefully remove the SST to prevent
gasoline from splashing.
(u) Using new gaskets, reconnect the cold start injector
pipe to the delivery pipe and cold start injector.
(v) Connect the wiring connector to the cold start injec–
tor.
(w) Start the engine and check for fuel leakage.
FUEL PUMP REMOVAL
1. DRAIN FUEL FROM FUEL TANK
CAUTION: Do not smoke or work near an open flame
when working on the fuel pump.
2. REMOVE FUEL TANK
3. REMOVE FUEL PUMP BRACKET
(a) Remove the seven bolts.
(b) Pull out the fuel pump bracket.
–ENGINE MFI SYSTEM
EG1–180
