Toyota 22R-E - Remove Intake Manifold with Delivery Pipe and Injectors; Remove EGR Valve; Remove Exhaust Manifold with No. 2 Secondary Air Injection Manifold; Remove Two Engine Hangers and Ground Strap

(b) Remove the bolt and the heater inlet pipe from the
cylinder head.
(c) Remove the seven bolts, one hexagon bolt, two nuts
and No. 1 air pipe.
(d) Remove the intake manifold together with the delivery
pipe, injectors and heater water inlet pipe.
4. REMOVE EXHAUST MANIFOLD WITH NO. 2 SEC–
ONDARY AIR INJECTION MANIFOLD
(a) Remove the three bolts and No. 2 exhaust manifold
heat insulator.
(b) Remove the eight nuts, exhaust manifold and No. 2
secondary air injection manifold.
5. REMOVE TWO ENGINE HANGERS AND GROUND
STRAP
6. REMOVE CYLINDER HEAD REAR OVER
2. REMOVE INTAKE MANIFOLD WITH DELIVERY
PIPE AND INJECTORS
(a) Remove the two nuts and reed valve.
3. REMOVE EGR VALVE
–ENGINE ENGINE MECHANICAL
EG1–20
