Toyota 22R-E - VC-E2 (E21); There Is no Voltage between ECM Terminals VC and E2 (E21) (IG SW ON)

(1) There is no voltage between ECM terminals Vc and E2 (E21).
(IG SW ON)
(2) Check that there is voltage between ECM terminals + B (+ B1)
and E1. (IG SW ON)
Check wiring between ECM and
volume air flow meter.
Intake air temperature 20C
(68 F)
(3) Check volume air flow
meter.
Replace or repair
volume air flow meter.
Replace or repair wiring.
Measuring plate fully closed
Measuring plate fully open
Ignition switch
ON
Try another ECM.
• Vc–E2 (E21)
Ignition
switch
ON
Refer to No. 1.
STD Voltage
. Terminals
No voltage
Condition
Trouble
Idling
BAD
BAD
No.
–ENGINE MFI SYSTEM
EG1–129
