Toyota 22R-E - Volume Air Flow (VAF) Meter On-Vehicle Inspection

VOLUME AIR FLOW (VAF) METER
ON–VEHICLE INSPECTION
MEASURE RESISTANCE OF VOLUME AIR FLOW
METER
(a) Disconnect the connector from the volume air flow
meter.
(b) Using an ohmmeter, measure the resistance between
each terminal.
If not within specification, replace the volume air flow
meter.
(c) Reconnect the volume air flow meter connector.
COMPONENTS FOR REMOVAL AND
INSTALLATION
Between
terminals
46°C (104° F)
60°C (140°F)
–20°C (4°F)
200–400C)
0.4–0.7k

200–600C)
0.9 – 1.3 k
20°C (68°F)
Temperature
10–20k

O° C (32°F)
Resistance
THA – E2
THA – E2
THA – E2
THA – E2
THA – E2
4 –7k
2 –3k
FC–E1
VS – e2
VC – e2
Infinity
–ENGINE MFI SYSTEM
EG2–233
