Toyota 22R-E - Connect Fuel Hose to Delivery Pipe; Connect Wires

8. CHECK FOR FUEL LEAKAGE
(a) With the ignition switch ON, use SST to connect
terminals Fp and +B of the DLC1.
SST 09843–18020
(b) Check for fuel leakage.
(c) Remove SST from the DLC1.
5. INSTALL CHAMBER WITH THROTTLE BODY
(See steps 7 to 14 on pages EG1–37, 38)
6. FILL WITH COOLANT
(See step 3 on page EG1–225)
7. CONNECT CABLE TO NEGATIVE TERMINAL OF
BATTERY
3. CONNECT FUEL HOSE TO DELIVERY PIPE
(a) Install the fuel hose with a bolt.
(b) Install the union bolt and new gaskets. Torque the
union bolt.
Torque: 44 N–m (450 kgf–cm, 33 ft–lbf)
4. CONNECT WIRES
(See step 5 on page EG1–36)
Turn the injector so that the injector positioning guide
is aligned with the positioning rib of the delivery pipe.
(d) install and torque the bolts.
Torque: 19 N–m (195 kgf–cm, 14 ft–lbf)
–ENGINE MFI SYSTEM
EG1–191
