(a) Disconnect the connector from the volume air flow
meter.
(b) Using an ohmmeter, measure the resistance between
each terminal.
ON–VEHICLE INSPECTION
MEASURE RESISTANCE OF VOLUME AIR FLOW METER
If not within specification, replace the volume air flow
meter.
VOLUME AIR FLOW (VAF) METER
Between
terminals
Temperature
Resistance
–ENGINE MFI SYSTEM
EG1–194
