27. REMOVE FRONT EXHAUST PIPE
(a) Disconnect the oxygen sensor connector.
(b) Disconnect the exhaust pipe from the exhaust mani–
fold.
(c) Remove the exhaust pipe clamp from the clutch
housing.
(d) Remove the exhaust pipe from the catalytic converter.
23. (4WD)
REMOVE TRANSFER UNDER COVER
24. (4WD)
REMOVE STABILIZER BAR
25. (4WD)
REMOVE FRONT PROPELLER SHAFT
(See PR section)
26. REMOVE NO.1 FRAME CROSSMEMBER
28. (M/T)
REMOVE CLUTCH RELEASE CYLINDER WITH
BRACKET FROM TRANSMISSION
29. (4WD)
REMOVE NO.1 FRONT FLOOR HEAT INSULATOR
AND BRAKE TUBE HEAT INSULATOR
30. (2WD)
REMOVE ENGINE REAR MOUNTING AND BRACKET
(a) Remove the four bolts from the engine rear mounting.
(b) Raise the transmission slightly by raising the engine
with a jack.
(c) Remove the four bolts from the support member.
(b) Remove the cross shaft from the body.
22. DISCONNECT SPEEDOMETER CABLE
NOTICE: Do not lose the felt dust protector and washers.
–ENGINE ENGINE MECHANICAL
EG1–49
