8. REMOVE FUEL PRESSURE REGULATOR
Loosen the lock nut, and remove the fuel pressure
regulator.
(q) Remove the six bolts, two nuts, intake chamber and
gasket.
(o) Disconnect the four vacuum hoses from the air pipes.
(p) Remove the two bolts and accelerator cable bracket.
(n) Disconnect the No.1 air hose from the PAIR reed
valve.
–ENGINE MFI SYSTEM
EG2–215

Toyota 22R-E Specifications

General

Displacement	2.4 L (2366 cc)
Fuel System	Electronic Fuel Injection (EFI)
Compression Ratio	9.0:1
Torque	142 lb⋅ft (193 N⋅m) at 3, 400 rpm
Block Material	Cast Iron
Head Material	Aluminum
Engine Type	Inline-4
Bore x Stroke	92 mm x 89 mm (3.62 in x 3.50 in)
Valvetrain	SOHC, 2 valves per cylinder
Power Output	112 hp (84 kW) at 4, 600 rpm
