(o) (C & C only)
Disconnect the two water by–pass hoses from the
EGR valve.
(p) Remove the five nuts, the EGR valve and pipes as–
sembly and two gaskets.
(r) Disconnect the four vacuum hoses from the air pipes.
(s) Remove the two bolts and accelerator cable bracket.
(t) Remove the six bolts, two nuts, intake chamber and
gasket.
(q) Disconnect the No.1 air hose from the PAIR reed
valve.
(n) Remove the nut, bolt and PS pump bracket.
–ENGINE ENGINE MECHANICAL
EG2–55
