OIL AND FILTER REPLACEMENT
NOTICE:
• Prolonged and repeated contact with mineral oil will
result in the removal of natural fats from the skin,
leading to dryness, irritation and dermatitis. In ad–
dition, used engine oil contains potentially harmful
contaminants which may cause skin cancer.
Adequate means of skin protection and washing
facilities should be provided.
• Care should be taken, therefore, when changing
engine oil, to minimize the frequency and length of
time your skin is exposed to used engine oil.
Protective clothing and gloves, that cannot be pen–
etrated by oil, should be worn. The skin should be
thoroughly washed with soap and water, or use
waterless hand cleaner, to remove any used engine
oil. Do not use gasoline, thinners, or solvents.
• In order to preserve the environment, used oil and
used oil filters must be disposed of only at desig–
nated disposal sites.
1. DRAIN ENGINE OIL
(a) Remove the oil filler cap.
(b) Remove the oil dipstick.
(c) Remove the oil drain plug and drain the oil into a
container.
(d) Tighten the filter by hand until the gasket contacts the
seat of the filter mounting. Then using SST, give it an
additional 3/4 turn to seat the filter.
SST 09228–07500
3. FILL WITH ENGINE OIL
(a) Clean and install the oil drain plug with a new gasket.
(b) Fill the engine with new oil, API grade SG Energy –
Conserving ll multigrade and recommended viscosity
oil.
2. REPLACE OIL FILTER
(a) Using SST, remove the oil filter (located on left side of
the cylinder block).
SST 09228–07500
(b) Clean the filter contact surface on the filter mounting.
(c) Apply clean engine oil to the gasket of a new oil filter.
–ENGINE LUBRICATION SYSTEM
EG2–278
