Installing the 2 Tray Module 1. Setting up the Phaser 790

Xerox Phaser 790 1-11

12. Remove the tape from the paper feed area access door, and then open

the door.

301010B-WOL

13. Remove the cardboard packing shown below.

301011B-WOL

14. Close the paper feed area access door.

The next step

Go to the Unpacking the Printer procedure in this chapter.
