1. Setting up the Phaser 790 Unpacking the Printer

1-18 Xerox Phaser 790

10. Remove all the tape from the exterior of the Printer:

a. Left side

301017B-WOL

0

b. Right Side

301018A-WOL

0

c. Inside the Front Cover

301019a
