Installing the Duplex Tray 1. Setting up the Phaser 790

Xerox Phaser 790 1-37

CAUTION

Ensure that the small connector and cable on the left-hand side of the Lower

Inverter are pulled back out of the way.

10. Install the Lower Inverter as shown below.

301057B-WOL

The Lower Inverter does not install flush with the Printer covers.

a. Install the two thumbscrews from the contents of the box.

301058B-WOL

SMALL

CONNECTOR

AND CABLE
