1. Setting up the Phaser 790 Installing the Duplex Tray

1-38 Xerox Phaser 790

b. Connect the small connector from the Lower Inverter to the small

jack located at the rear of the left-hand side of the Printer.

301059A-WOL

c. Reinstall the small Access Cover.

301060B-WOL

11. Install the Upper Inverter:

a. Install the Upper Inverter into the Printer as shown.

301061B-WOL
