Installing the Duplex Tray 1. Setting up the Phaser 790
Xerox Phaser 790 1-39
b. Connect the tiny connector on the rear of the Upper Inverter to the
small jack in the access hole, as shown below.
301132A-WOL
0
0301062b
c. Install the new Connector Cover with the cutout into the access
hole, guiding the wires through the cutout in the cover.
301133A-WOL
0
301063b
CAUTION
Use caution if you must rearrange the tiny wires on the connector in order to
close the Connector Cover.
