1. Setting up the Phaser 790 Installing the Duplex Tray

1-40 Xerox Phaser 790

12. Reinstall the Output Tray.

301032B-WOL

13. Connect the power cord to the Printer and the wall outlet.

301071B-WOL

The next step

Go to the Loading the paper in the paper tray procedure.
