3. Network Setup Token Ring Network Kit

3-4 Xerox Phaser 790

10. Connect the network cable.

301254a

11. Reconnect the power cord to the rear of the Printer.

12. Switch ON the Printer power. After a few moments, READY is displayed

on the Control Panel.
