Token Ring Network Kit 3. Network Setup

Xerox Phaser 790 3-3

7. Insert the left-hand side Printer panel into place as shown.

301218a

8. Press the panel closed and slide it to the left.

301216

9. Reinstall the three screws into the side panel.

301070a
