Adva 3000R7 - Page 126

MP-2B4CT
Protocols
l OTU4 100 Gb transport signal
l Proprietary 200 Gb high speed transport
signal
l Proprietary 300 Gb high speed transport
signal
Loop functionality Facility loop
Service/channel density 96 channels at 50 GHz spacing, 128
channels at 37.5 GHz spacing
Tuning range 1528.57 nm (196.100000 THz) to 1567.64
nm (191.23750 THz)
Tuning resolution 6.25 GHz
Frequency stability ±1.8 GHz
Tx optical power range 0 dBm to +6 dBm
Tx optical power accuracy ±1.5 dB
Tx wavelength switching time <60 s
Receiver dynamic range
l 100G QPSK: –30 dBm to +10 dBm
l 150G/300G 8QAM: –26 dBm to +10
dBm
l 200G 16QAM: –23 dBm to +10 dBm
OPR measurement range –33 dBm to +13 dBm
OPR measurement accuracy
l ±1.5 dB over range of –18 dBm to +1
dBm
l ±2.5 dB over range of –33 dBm to +13
dBm.
Protocols OTU4
Modulation DP-QPSK
FEC
l 3 iteration 15% SD FEC (compatible with other FSP
3000R7 modules supporting OTU4)
l 5 iteration 15% SD FEC
l 5 iteration 25% SD FEC
l 1 iteration 25% SD FEC (low latency)
Embedded communication
channels for OTU4 service
GCC0 (13702 kb/s), GCC1 (13702 kb/s), GCC2 (13702
kb/s)
PMD tolerance 30 ps
CD tolerance –280,000 ps/nm to +6,000 ps/nm based on selected
range:
l Range 1: –22,000 ps/nm to +6,000 ps/nm
l Range 2: –72,000 ps/nm to +6,000 ps/nm
l Range 3: –120,000 ps/nm to +6,000 ps/nm
l Range 4: –280,000 ps/nm to +6,000 ps/nm
OSNR sensitivity 25% OH
5 iteration SD-FEC –18
dBm (Rx power)
11.0 dB
Table 65: 100 Gb Network Interface
