Adva 3000R7 - Page 127

MP-2B4CT
Protocols Proprietary 200G transport signal
Modulation 16 QAM
FEC
l 5 iteration 15% SD FEC
l 5 iteration 25% SD FEC
l 1 iteration 25% SD-FEC (low latency)
PMD tolerance 20 ps
CD tolerance –45,000 ps/nm to +5,000 ps/nm based on selected
range:
l Range 1: –20,000 ps/nm to +2,000 ps/nm
l Range 2: –45,000 ps/nm to +5,000 ps/nm
OSNR sensitivity 25% OH 5
iteration SD-FEC –18 dBm
(Rx power)
19.5 dB
Table 66: 200 Gb Network Interface
Protocols Proprietary 300G high speed transport signal
Lanes Two 150G lanes
Modulation per 150G lane 8 QAM
FEC per 150G lane
l 5 iteration 15% SD FEC
l 5 iteration 25% SD FEC
l 1 iteration 25% SD-FEC (low latency)
Supported fault
management (FM)
l PHY: LASER Fail, LASER On Delay, LOS-P, LOS,
LBCAbnormal, LASERTemp H/L
l OCh: Loss of Modem Sync
l OTLC1P5A: LOF, LOM
l OTUC3PA: DEG
l ODUC3PAjk: LOFLOM
l ODU4: OCI, LCK, BDI, TIM, DEG
PMD tolerance per 150G
lane
20 ps
CD tolerance per 150G
lane
–45,000 ps/nm to +5,000 ps/nm based on selected range:
l Range 1: –20,000 ps/nm to +2,000 ps/nm
l Range 2: –45,000 ps/nm to +5,000 ps/nm
OSNR sensitivity 25% OH
5 iteration SD-FEC –18
dBm (Rx power) per 150G
lane
16.0 dB
Table 67: 300 Gb Network Interface
