SH4R Shelf
Parameter Value Notes
Nominal/rated current
l 1+0: 8.7 to 3.6 A @ 100 to 240 VAC
l 2+0 and 2+1: 15.3 to 6.4 A @ 100 to
240 VAC
l 1+1: 13.0 to 5.4 A @ 100 to 240 VAC
PSM-AC4
1
l 1+0: 15.8 to 6.5 A @ 100 to 240 VAC
l 1+1: 15.3 to 6.3 A @ 100 to 240 VAC
PSM-AC5
1
l 1+0: 18.0 A @ –48 VDC
l 1+1, 2+0, and 2+1:32.0 A @ –48
VDC
PSM-DC4
l 1+1:
o
8.7 to 3.6 A @ 100 to 240 VAC
o
18 A @ –48 VDC
l 2+1:
o
15.3 to 6.3 A @ 100 to 240 VAC
o
32 A @ –48 VDC
Mixed PSM-AC5/PSM-DC4
Power consumption
(fully equipped with 7 traffic
modules)
1035 W @ 100 to 240 VAC Typical (PSM-AC4/PSM-AC5)
1584 W @ 100 to 240 VAC Maximum (PSM-AC4/PSM-AC5)
1035 W @ –48 VDC Typical (PSM-DC4)
1533 W @ –48 VDC Maximum (PSM-DC4)
Maximum power
1
1+0 (non-redundant) power configuration
l 870 W @ 100 to 240 VAC
l 8.7 A @ 100 VAC
l 7.3 A @ 120 VAC
l 3.6 A @ 240 VAC
PSM-AC4
1+1 (redundant) power configuration
l 1304 W @ 100 to 240 VAC
l 13.0 A @ 100 VAC
l 10.9 A @ 120 VAC
l 5.4 A @ 240 VAC
2+0 (non-redundant) and 2+1 (redundant)
power configurations
l 1533 W @ 100 to 240 VAC
l 15.3 A @ 100 VAC
l 12.8 A @ 120 VAC
l 6.4 A @ 240 VAC
Table 5: General Information — SH4R
43 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
