SH4R Shelf
Parameter Value Notes
1+0 (non-redundant) power configuration
l 1584 W @ 100 to 240 VAC
l 15.8 A @ 100 VAC
l 13.2 A @ 120 VAC
l 6.5 A @ 240 VAC
PSM-AC5
1+1 (redundant) power configuration
l 1533 W @ 100 to 240 VAC
l 15.3 A @ 100 VAC
l 12.8 A @ 120 VAC
l 6.3 A @ 240 VAC
1+0 (non-redundant) and 1+1
(redundant)power configurations
l 870 W @ –48 V
l 18 A @ –48 V
PSM-DC4
2+0 (non-redundant) and 2+1 (redundant)
power configurations
l 1533 W @ –48 V
l 32 A @ –48 V
1+1 (redundant) configuration
l 870 W @ 100 to 240 VAC
l 870 W @ –48 V
l 8.7 A @ 100 VAC
l 7.3 A @ 120 VAC
l 3.6 A @ 240 VAC
l 18 A @ –48 V
Mixed PSM-AC5/PSM-DC4
2+1 (redundant) configuration
l 1533 W @ 100 to 240 VAC
l 1533 W @ –48 V
l 15.3 A @ 100 VAC
l 12.8 A @ 120 VAC
l 6.3 A @ 240 VAC
l 32 A @ –48 V
Table 5: General Information — SH4R
