CEM-3
l SH1R Shelf
l Specifications
l Port Pinouts
l Slot Numbers and Assignments
l FTM-3
Specifications
Electrical connector type FireWire (6-pins)
Cable type IEEE 1394 interface cable
Signals
l I
2
C (2 pins)
l Shelf detect (1 pin)
l Power (3V3 and ground, 2 pins)
Table 17: Specifications — Interconnect Ports
Even though some FSP 3000R7 components use FireWire connectors to
interconnect, the connectors do not support the FireWire protocol or
pinouts.
Electrical connector type RJ-45
Receptacle type 8P8C
Data signal IEEE 802.3 100Mb/1G Ethernet
Cable type
l Unshielded for cable length: < 3 m
l Shielded (S/FTP) for cable length: 3 m to 100 m
Maximum link distance 100 m (328 ft)
Performance
l 10/100 Mb/s/1G Ethernet half/full duplex
l 10/100 Mb/s/1G Ethernet auto-negotiation can be
disabled
l Autosense
l Automatic MDI/MDI-X crossover capabilities
Compliance standards
l IEEE 802.3 10/100BASE-TX
l IEEE 802.3u
Table 18: Specifications — Management Ports
79 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
