ECM-3
Figure 29: ECM-3 Faceplate
Parameter Value Notes
Sales item number 1063801063-01
Release introduced FSP3000R7 Release 17.1
Compatible shelves
l SH1R
Width 108 mm (4.3 in.)
Height 20 mm (0.8 in.)
Weight 0.4 kg (0.9 lbs)
Power consumption 11 W Typical
14 W Maximum
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 23: General Information — ECM-3
To prevent airflow shortcut, you must reinsert or replace the ECM-3
within one minute.
l Environmental Specifications
l MTBF Hours for HDEquipment
l SH1R Shelf
l Slot Numbers and Assignments
l Cables
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 86
