6.4 Critical and Noncritical Interrupts
The PPC405 processes interrupts as noncritical and critical. The following interrupts are defined as noncritical:
data storage, instruction storage, an active external interrupt input, alignment, program, system call, programmable
interval timer (PIT), fixed interval timer (FIT), data TLB miss, and instruction TLB miss. The following interrupts are
defined as critical: machine check interrupts (instruction- and data-side), debug interrupts, interrupts caused by an
active critical interrupt input, and the first time-out from the watchdog timer.
When a noncritical interrupt is taken, Save/Restore Register 0 (SRR0) is written with the address of the excepting
instruction (most synchronous interrupts) or the next sequential instruction to be processed (asynchronous
interrupts and system call).
If the PPC405 was executing a multicycle instruction (multiply, divide, or cache operation), the instruction is
terminated and its address is written in SRR0.
Aligned scalar loads/stores that are interrupted do not appear on the PLB. An aligned scalar load/store cannot be
interrupted after it is requested on the PLB, so the Guarded (G) storage attribute does not need to prevent the
interruption of an aligned scalar load/store.
To enhance performance, the DCU can respond to non cacheable load requests by retrieving a line instead of a
word. This is controlled by CCR0[LWL]. Note, however, that If CCR0[LWL] = 1, and the target non cacheable
region is also marked as guarded (the G storage attribute is set to 1), that the DCU will request on the PLB only
those bytes requested by the CPU.
Load/store multiples, load/store string, and misaligned scalar loads/stores that cross a word boundary can be
interrupted and restarted upon return from the interrupt handler.
When load instructions terminate, the addressing registers are not updated. This ensures that the instructions can
be restarted; if the addressing registers were in the range of registers to be loaded, this would be an invalid form in
any event. Some target registers of a load instruction may have been written by the time of the interrupt; when the
instruction restarts, the registers will simply be written again. Similarly, some of the target memory of a store
instruction may have been written, and is written again when the instruction restarts.
11 Data TLB miss Noncritical Valid matching entry for the effective address and process ID of an attempted
data access is not found in the TLB
12 Data storage—ZPR[Z
n] = 00 Noncritical Data translation is active and data-side access to the translated address is not
permitted because ZPR[Z
n] = 00 in user mode
13 Data storage—
TLB_entry[WR] = 0
Noncritical Data translation is active and write access to the translated address is not
permitted because TLB_entry[WR] = 0
Data storage—
TLB_entry[U0] = 1 or
SU0R[U
n]=1
Noncritical Data translation is active and write access to the translated address is not
permitted because TLB_entry[U0] = 1 or SU0R[U
n]=1
14 Alignment Noncritical
dcbz to non cacheable address or write-through storage; non-word aligned
dcread, lwarx, and stwcx, as described in Table 6-10
15 Debug—BT, DAC, DVC, IC,
TIE
Critical BT, DAC, DVC, IC, TIE debug event (in internal debug mode)
16 External interrupt input Noncritical Active level on the external interrupt input by the UIC
17 Fixed Interval Timer (FIT) Noncritical Posting of an enabled FIT interrupt in the TSR
18 Programmable Interval Timer
(PIT)
Noncritical Posting of an enabled PIT interrupt in the TSR
Table 6-1. Interrupt Handling Priorities (Continued)
Priority Interrupt Type
Critical or
Noncritical
Causative Conditions
