AMCC PPC405 - 6.17 Data TLB Miss Interrupt; 6.18 Instruction TLB Miss Interrupt

AMCC Proprietary 127
Revision 1.02 - September 10, 2007
PPC405 Processor
Preliminary User’s Manual
6.17 Data TLB Miss Interrupt
The data TLB miss interrupt is generated if data translation is enabled and a valid TLB entry matching the EA and
PID is not present. The address of the instruction generating the untranslatable effective data address is saved in
SRR0. In addition, the hardware also saves the data address (that missed in the TLB) in the DEAR. The ESR is set
to indicate whether the excepting operation was a store (includes dcbz, dcbi, dccci). The interrupt is precise.
Program flow vectors to EVPR[0:15] || 0x1100.
The following registers are modified to the values specified in Table 6-18.
Programming Note: Data TLB miss interrupts can happen whenever data translation is enabled. Therefore,
ensure that SRR0 and SRR1 are saved before enabling translation in an interrupt handler.
6.18 Instruction TLB Miss Interrupt
The instruction TLB miss interrupt is generated if instruction translation is enabled and execution is attempted for
an instruction for which a valid TLB entry matching the EA and PID for the instruction fetch is not present. The
instruction whose fetch caused the TLB miss is saved in SRR0.
The interrupt is precise with respect to the attempted execution of the instruction. Program flow vectors to
EVPR[0:15 || 0x1200.
The following are modified to the values specified in Table 6-19.
Programming Note: Instruction TLB miss interrupts can happen whenever instruction translation is active.
Therefore, insure that SRR0 and SRR1 are saved before enabling translation in an interrupt handler.
Table 6-18. Register Settings during Data TLB Miss Interrupts
SRR0 Set to the address of the instruction generating the effective address for
which no valid translation exists.
SRR1 Set to the value of the MSR at the time of the interrupt
PC EVPR[0:15] || 0x1100
DEAR Set to the effective address of the failed access
ESR DST ← 1 if excepting operation is a store operation (includes
dcbi, dcbz,
and
dccci).
MCI ← unchanged
All other bits are cleared.
Table 6-19. Register Settings during Instruction TLB Miss Interrupts
SRR0 Set to the address of the instruction for which no valid translation exists.
SRR1 Set to the value of the MSR at the time of the interrupt
PC EVPR[0:15] || 0x1200
