B.9 Comparison Instructions
Comparison instructions perform arithmetic and logical comparisons between two operands and set one of the
eight condition code register fields based on the outcome of the comparison. Table B-10 shows the comparison
instructions supported by the PPC405.
Table B-9. Branch Instructions
Mnemonic Operands Function
Other Registers
Changed
Page
b target Branch unconditional relative.
LI
← (target – CIA)
6:29
NIA ← CIA + EXTS(LI ||
2
0)
174
ba Branch unconditional absolute.
LI
← target
6:29
NIA ← EXTS(LI ||
2
0)
bl Branch unconditional relative.
LI
← (target – CIA)
6:29
NIA ← CIA + EXTS(LI ||
2
0)
(LR)
← CIA + 4.
bla Branch unconditional absolute.
LI
← target
6:29
NIA ← EXTS(LI ||
2
0)
(LR) ← CIA + 4.
bc BO, BI, target Branch conditional relative.
BD
← (target – CIA)
16:29
NIA ← CIA + EXTS(BD ||
2
0)
CTR if BO
2
= 0. 175
bca Branch conditional absolute.
BD
← target
16:29
NIA ← EXTS(BD ||
2
0)
CTR if BO
2
= 0.
bcl Branch conditional relative.
BD ← (target – CIA)
16:29
NIA ← CIA + EXTS(BD ||
2
0)
CTR if BO
2
= 0.
(LR) ← CIA + 4.
bcla Branch conditional absolute.
BD ← target
16:29
NIA ← EXTS(BD ||
2
0)
CTR if BO
2
= 0.
(LR) ← CIA + 4.
bcctr BO, BI Branch conditional to address in CTR.
Using (CTR) at exit from instruction,
NIA
← CTR
0:29
||
2
0.
CTR if BO
2
= 0. 181
bcctrl CTR if BO
2
= 0.
(LR)
← CIA + 4.
bclr BO, BI Branch conditional to address in LR.
Using (LR) at entry to instruction,
NIA ← LR
0:29
||
2
0.
CTR if BO
2
= 0. 184
bclrl CTR if BO
2
= 0.
(LR) ← CIA + 4.
Table B-10. Comparison Instructions
Mnemonic Operands Function
Other Registers
Changed
Page
cmp BF, 0, RA, RB Compare (RA) to (RB), signed.
Results in CR[CRn], where
n = BF.
188
cmpi BF, 0, RA, IM Compare (RA) to EXTS(IM), signed.
Results in CR[CRn], where
n = BF.
189
cmpl BF, 0, RA, RB Compare (RA) to (RB), unsigned.
Results in CR[CRn], where
n = BF.
190
