6.7.2 Data Machine Check Handling
When a machine check occurs on an data access, a machine check—data interrupt occurs. To determine the
cause of a machine check, examine the various error reporting registers of the external PLB slaves.
6.8 Data Storage Interrupt
The data storage interrupt occurs when the desired access to the effective address is not permitted for any of the
following reasons:
• A U0 fault: any store to an EA with the U0 storage attribute set and CCR0[U0XE] = 1
• In the problem state with data translation enabled:
–A zone fault, which is any user-mode storage access (data load, store, icbi, dcbz, dcbst, or dcbf) with an
effective address with (ZPR field) = 00. (dcbt and dcbtst will no-op in this situation, rather than cause an
interrupt. The instructions dcbi, dccci, icbt, and iccci, being privileged, cannot cause zone fault data stor-
age interrupts.)
– Data store or dcbz to an effective address with the WR bit clear and (ZPR field) ¼ 11. (The privileged
instructions dcbi and dccci are treated as “stores,” but will cause privileged program interrupts, rather than
data storage interrupts.)
• In the supervisor state with data translation enabled:
– Data store, dcbi, dcbz, or dccci to an effective address with the WR bit clear and (ZPR field) other than 11
or 10.
Programming Note: The icbi, icbt, and iccci instructions are treated as loads from the addressed byte with
respect to address translation and protection. Instruction cache operations use MSR[DR], not MSR[IR], to
determine translation of their operands. Instruction storage interrupts and Instruction-side TLB Miss Interrupts
are associated with the fetching of instructions, not with the execution of instructions. Data storage interrupts
and data TLB miss interrupts are associated with the execution of instruction cache operations.
When a data storage interrupt is detected, the PPC405 suppresses the instruction causing the interrupt and writes
the instruction address in SRR0. The Data Exception Address Register (DEAR) is loaded with the data address
that caused the access violation. ESR bits are loaded as shown in Table 6-7 on page 121 to provide further
information about the error. The current contents of the MSR are loaded into SRR1, and MSR bits are then loaded
with the values shown in Table 6-7 on page 121.
The high-order 16 bits of the program counter are then loaded with the contents of the EVPR and the low-order 16
bits of the program counter are loaded with 0x0300. Interrupt processing begins at the new address in the program
counter. Executing the return from interrupt instruction (rfi) restores the contents of the program counter and the
MSR from SRR0 and SRR1, respectively, and the PPC405 resumes execution at the new program counter
address.
For instructions that can simultaneously generate program interrupts (privileged instructions executed in Problem
State) and data storage interrupts, the program interrupt has priority.
Table 6-6. Register Settings during Machine Check—Data Interrupts
SRR2 Written with the address of the next sequential instruction.
SRR3 Written with the contents of the MSR
PC EVPR[0:15] || 0x0200
