AMCC PPC405 - Table 9-11. Extended Mnemonics for Cmpi

AMCC Proprietary 189
Revision 1.02 - September 10, 2007
PPC405 Processor
cmpi
Compare Immediate
Preliminary User’s Manual
cmpi
Compare Immediate
c
0:3
←
4
0
if (RA) < EXTS(IM) then c
0
← 1
if (RA) > EXTS(IM) then c
1
← 1
if (RA) = EXTS(IM) then c
2
← 1
c
3
← XER[SO]
n
← BF
CR[CRn] ← c
0:3
The IM field is sign-extended to 32 bits. The contents of register RA are compared with the extended IM field, using
a 32-bit signed compare.
The CR field specified by the BF field is updated to reflect the results of the compare and the value of XER[SO] is
placed into the same CR field.
Registers Altered
• CR[CRn] where n is specified by the BF field
Invalid Instruction Forms
• Reserved fields
Programming Note
The PowerPC Architecture defines this instruction as cmpi BF,L,RA,IM, where L selects operand size for 64-bit
PowerPC implementations. For all 32-bit PowerPC implementations, L = 0 is required (L = 1 is an invalid form);
hence for the PPC405, use of the extended mnemonic cmpwi BF,RA,IM is recommended.
Architecture Note
This instruction is part of the PowerPC User Instruction Set Architecture.
cmpi BF, 0, RA, IM
11 BF
RA IM
0691116 31
Table 9-11. Extended Mnemonics for cmpi
Mnemonic Operands Function
Other Registers
Altered
cmpwi [BF,] RA, IM
Compare Word Immediate.
Use CR0 if BF is omitted.
Extended mnemonic for
cmpi BF,0,RA,IM
