AMCC Proprietary 151
Revision 1.02 - September 10, 2007
PPC405 Processor
Preliminary User’s Manual
The user must determine how the addresses of interest are accessed, relative to byte, halfword, word, string, and
unaligned storage instructions, and adjust the DAC compare size field appropriately to cover the addresses of
interest.
For example, suppose that a DAC debug event should react to byte 3 of a word-aligned target. A DAC set for exact
compare would not recognize a reference to that byte by load/store word or load/store halfword instructions,
because the byte address is not the EA of such instructions. In such a case, the D1S field must be set for a wider
capture range (for example, to ignore the two least significant bits (LSBs) if word operations to the misaligned byte
are to be detected). The wider capture range may result in excess debug events (events that are within the
specified capture range, but reflect byte operations in addition to the desired byte). Such excess debug events
must be handled by software.
While load/store string instructions are inherently byte addressed the processor will generate EAs containing the
largest portion of an aligned word address as possible. It may not be possible to DAC on a specific individual byte
using load/store string instructions.
8.8.13.2 DAC Range Address Compare
In this mode, the pair of DAC1 and DAC2 registers are used to define a range of addresses to compare.
To enable DAC range, DBCR1[DA12] = 1 and one or more of DBCR1[D1R,D2R,D1W,D2W] =1. The DAC event is
seen on the DBSR[DR1,DR2,DW1,DW2] field that corresponds to the DBCR1[D1R,D2R,D1W,D2W] field that is
enabled. For example, if DBCR1[D1R] and DBCR1[D2R] are enabled, the results of a DAC debug event are
reported on DBSR[DR1, DR2]. Setting DBCR1[DA12] =1 prohibits DAC1 and DAC2 from being used for exact
address compares.
Ranges are defined to be inclusive or exclusive, using the DBCR1[DA12X], as follows:
DBCR1[DA12] = 1: Range = DAC1 ≤ range < DAC2.
DBCR1[DA12X] = 1: Range = Range low < DAC1 or DAC2 ≤ Range high.
Figure 8-9 shows the range selected in an inclusive DAC range address compare. Note that the address in DAC1
is considered part of the range, but the address in DAC2 is not, as shown in the preceding examples. The thick
lines indicate that the indicated address is included in the compare results.
Figure 8-10 shows the range selected in an exclusive DAC range address compare. Note that the address in DAC1
is not considered part of the range, but the address in DAC2 is, along with the highest memory address, as shown
in the preceding examples.
DAC 1 Size
00 Compare all bits
01 Ignore LSB (least significant bit)
10 Ignore two LSBs
11 Ignore five LSBs
Byte address
Halfword address
Word address
Cache line (
8-word) address
Figure 8-9. Inclusive DAC Range Address Compares
DAC1 DAC2
0
FFFF FFFF
