6.9 Instruction Storage Interrupt
The instruction storage interrupt is generated when instruction translation is active and execution is attempted for
an instruction whose fetch access to the effective address is not permitted for any of the following reasons:
• In Problem State:
– Instruction fetch from an effective address with (ZPR field) = 00.
– Instruction fetch from an effective address with the EX bit clear and (ZPR field) ¼ 11.
– Instruction fetch from an effective address contained within a Guarded region (G=1).
• In Supervisor State:
– Instruction fetch from an effective address with the EX bit clear and (ZPR field) other than 11 or 10.
– Instruction fetch from an effective address contained within a Guarded region (G=1).
SRR0 will save the address of the instruction causing the instruction storage interrupt.
ESR is set to indicate the following conditions:
• If ESR[DIZ] = 1, the excepting condition was a zone fault: the attempted execution of an instruction address
fetched in user-mode with (ZPR field) = 00.
• If ESR[DIZ] = 0, then the excepting condition was either EX = 0 or G = 1.
The interrupt is precise with respect to the attempted execution of the instruction. Program flow vectors to
EVPR[0:15] || 0x0400.
The following registers are modified to the specified values:
Table 6-7. Register Settings during Data Storage Interrupts
SRR0 Written with the EA of the instruction causing the data storage interrupt
SRR1 Written with the value of the MSR at the time of the interrupt
PC EVPR[0:15] || 0x0300
DEAR Written with the EA of the failed access
ESR DST ← 1 if excepting operation is a store
DIZ ← 1 if access failure caused by a zone protection fault (ZPR[Z
n] = 00 in
user mode)
U0F ← 1 if access failure caused by a U0 fault (the U0 storage attribute is set
and CCR0[U0XE] = 1)
MCI ← unchanged
All other bits are cleared.
