PPC405 Processor
Preliminary User’s Manual
6.14 Programmable Interval Timer (PIT) Interrupt
For a discussion of the PPC405 timer facilities, see Timer Facilities on page 129. The PIT is described in
Programmable Interval Timer (PIT) on page 131.
If the PIT interrupt is enabled by TCR[PIE] and MSR[EE], the PPC405 initiates a PIT interrupt after detecting a
time-out from the PIT. Time-out is detected when, at the beginning of a clock cycle, TSR[PIS] = 1. (This occurs on
the cycle after the PIT decrements on a PIT count of 1.) The PPC405 immediately takes the interrupt. The address
of the next sequential instruction is saved in SRR0; simultaneously, the contents of the MSR are written into SRR1
and the MSR is written with the values shown in Table 6-15. The high-order 16 bits of the program counter are then
written with the contents of the EVPR and the low-order 16 bits of the program counter are written with 0x1000.
Interrupt processing begins at the address in the program counter.
To clear a PIT interrupt, the interrupt handling routine must clear the PIT interrupt bit, TSR[PIS]. Clearing is
performed by writing a word to TSR, using an mtspr instruction, that has 1 in bit positions to be cleared and 0 in all
other bit positions. The data written to the TSR is not direct data, but a mask; a 1 clears the bit and 0 has no effect.
Executing an rfi instruction restores the program counter from SRR0 and the MSR from SRR1, and execution
resumes at the address in the program counter.
6.15 Fixed Interval Timer (FIT) Interrupt
For a discussion of the PPC405 timer facilities, see Timer Facilities on page 129. The FIT is described in Fixed
Interval Timer (FIT) on page 132.
If the FIT interrupt is enabled by TCR[FIE] and MSR[EE], the PPC405 initiates a FIT interrupt after detecting a
time-out from the FIT. Time-out is detected when, at the beginning of a clock cycle, TSR[FIS] = 1. (This occurs on
the second cycle after the 0 → 1 transition of the appropriate time-base bit.) The PPC405 immediately takes the
interrupt. The address of the next sequential instruction is written into SRR0; simultaneously, the contents of the
MSR are written into SRR1 and the MSR is written with the values shown in Table 6-16. The high-order 16 bits of
the program counter are then written with the contents of the EVPR and the low-order 16 bits of the program
counter are written with 0x1010. Interrupt processing begins at the address in the program counter.
Table 6-14. Register Settings during System Call Interrupts
SRR0 Written with the address of the instruction following the sc instruction
SRR1 Written with the contents of the MSR
PC EVPR[0:15] || 0x0C00
Table 6-15. Register Settings during Programmable Interval Timer Interrupts
SRR0 Written with the address of the next instruction to be executed
SRR1 Written with the contents of the MSR
PC EVPR[0:15] || 0x1000
TSR PIS ← 1
