AMCC PPC405 - Storage Reference Instructions

AMCC Proprietary 417
Revision 1.02 - September 10, 2007
PPC405 Processor
Preliminary User’s Manual
B.5 Storage Reference Instructions
The PPC405 uses load and store instructions to transfer data between memory and the general purpose registers.
Load and store instructions operate on byte, halfword and word data. The storage reference instructions also
support loading or storing multiple registers, character strings, and byte-reversed data. Table B-6 shows the
storage reference instructions available for use in the PPC405.
tweqi RA, IM Trap if (RA) equal to EXTS(IM).
Extended mnemonic for
twi 4,RA,IM
344
twgei Trap if (RA) greater than or equal to EXTS(IM).
Extended mnemonic for
twi 12,RA,IM
twgti Trap if (RA) greater than EXTS(IM).
Extended mnemonic for
twi 8,RA,IM
twlei Trap if (RA) less than or equal to EXTS(IM).
Extended mnemonic for
twi 20,RA,IM
twlgei Trap if (RA) logically greater than or equal to EXTS(IM).
Extended mnemonic for
twi 5,RA,IM
twlgti Trap if (RA) logically greater than EXTS(IM).
Extended mnemonic for
twi 1,RA,IM
twllei Trap if (RA) logically less than or equal to EXTS(IM).
Extended mnemonic for
twi 6,RA,IM
twllti Trap if (RA) logically less than EXTS(IM).
Extended mnemonic for
twi 2,RA,IM
twlngi Trap if (RA) logically not greater than EXTS(IM).
Extended mnemonic for
twi 6,RA,IM
twlnli Trap if (RA) logically not less than EXTS(IM).
Extended mnemonic for
twi 5,RA,IM
twlti Trap if (RA) less than EXTS(IM).
Extended mnemonic for
twi 16,RA,IM
twnei Trap if (RA) not equal to EXTS(IM).
Extended mnemonic for
twi 24,RA,IM
twngi Trap if (RA) not greater than EXTS(IM).
Extended mnemonic for
twi 20,RA,IM
twnli Trap if (RA) not less than EXTS(IM).
Extended mnemonic for
twi 12,RA,IM
Table B-5. Extended Mnemonics for PPC405 (Continued)
Mnemonic Operands Function
Other Registers
Changed
Page
