AMCC Proprietary 46
Revision 1.02 - September 10, 2007
PPC405 Processor
Preliminary User’s Manual
2.5.3 Endian (E) Storage Attribute
The endian (E) storage attribute supports direct connection of the PPC405 to little endian peripherals and to
memory containing little endian instructions and data. For every storage reference (instruction fetch or load/store
access), an E storage attribute is associated with the storage region of the reference. The E attribute specifies
whether that region is organized as big endian (E = 0) or little endian (E = 1).
When address translation is enabled (MSR[IR] = 1 or MSR[DR] = 1), the E field in the corresponding TLB entry
controls the endianness of a memory region. When address translation is disabled (MSR[IR] = 0 or MSR[DR] = 0),
the SLER controls the endianness of a memory region.
Bytes in storage that are accessed as little endian are arranged in true little endian format. The PPC405 does not
support the little endian mode defined in the PowerPC architecture and used in PPC401xx and PPC403xx
processors. Furthermore, no address modification is performed when accessing storage regions programmed as
little endian. Instead, the PPC405 reorders the bytes as they are transferred between the processor and memory.
The on-the-fly reversal of bytes in little endian storage regions is handled in one of two ways, depending on
whether the storage access is an instruction fetch or a data access (load/store). The following sections describe
byte reordering for the two kinds of storage accesses.
2.5.3.1 Fetching Instructions from Little Endian Storage Regions
Instructions are words (four bytes) that are aligned on word boundaries in memory. As such, instructions in a big
endian memory region are arranged with the most significant byte (MSB) of the instruction word at the lowest
address.
Consider the big endian mapping of instruction p at address 00, where, for example, p = add r7, r7, r4:
On the other hand, in the little endian mapping instruction p is arranged with the least significant byte (LSB) of the
instruction word at the lowest numbered address:
When an instruction is fetched from memory, the instruction must be placed in the instruction queue in the proper
order. The execution unit assumes that the MSB of an instruction word is at the lowest address. Therefore, when
instructions are fetched from little endian storage regions, the four bytes of an instruction word are reversed before
the instruction is decoded. In the PPC405, the byte reversal occurs between memory and the instruction cache unit
(ICU). The ICU always stores instructions in big endian format, regardless of whether the memory region
containing the instruction is programmed as big endian or little endian. Thus, the bytes are already in the proper
order when an instruction is transferred from the ICU to the decode stage of the pipeline.
Table 2-6. Big Endian Mapping
MSB LSB
0x00 0x01 0x02 0x03
Table 2-7. Little Endian Mapping
LSB MSB
0x00 0x01 0x02 0x03
