AMCC Proprietary 201
Revision 1.02 - September 10, 2007
PPC405 Processor
dcba
Data Cache Block Allocate
Preliminary User’s Manual
dcba
Data Cache Block Allocate
EA ← (RA|0) + (RB)
DCBA(EA)
An effective address (EA) is formed by adding an index to a base address. The index is the contents of register RB.
The base address is 0 if the RA field is 0 and is the contents of register RA otherwise.
If the data block at the EA is in the data cache and the EA is marked as cacheable and non-write-through, the data
in the cache block is architecturally undefined. For the PPC405, the cache data block is set to 0.
If the data block at the EA is not in the data cache and the EA is marked as cacheable and not marked as write-
through, a cache block is established and set to an architecturally-undefined value. Note that no data is read from
main storage, as described in the programming note.
If the data block at the EA is marked as non cacheable, a no-op occurs.
If the data block at the EA is in the data cache and marked as write-through, architecturally the data in the cache
block can be left unmodified. Alternatively, the data block at the EA can be undefined in the data cache and in main
storage. For the PPC405, a no-op occurs.
If the data block at the EA is not in the data cache and marked as write-through, architecturally the instruction can
establish a cache block and set the block to 0, or a no-op can occur. For the PPC405, a no-op occurs.
If instruction bit 31 contains 1, the contents of CR[CR0] are undefined.
Registers Altered
•None
Invalid Instruction Forms
• Reserved fields
Programming Notes
Because dcba can establish an address in the data cache without copying the contents of that address from main
storage, the address established can be invalid with respect to main storage. A subsequent operation may cause
the address to be copied back to main storage, for example, to make room for a new cache block; a machine check
exception could occur under these circumstances.
dcba provides a hint that a block of storage will soon be stored to or no longer needed; there is no need to retain
the data in the block. Establishing the line in the cache, without reading from main storage, improves performance.
Exceptions
This instruction is considered a “store” with respect to data storage exceptions. However, this instruction does not
cause data storage exceptions or data TLB-miss exceptions. If conditions occur that would otherwise cause such
exceptions, dcba is treated as a no-op.
dcba RA, RB
31
RA RB 758
0 6 11 16 21 31
