AMCC PPC405 - Page 391

AMCC Proprietary 391
Revision 1.02 - September 10, 2007
PPC405 Processor
Preliminary User’s Manual
19 417 XL crorc BT, BA, BB 199
19 449 XL
cror BT, BA, BB 198
19 528 XL
bcctr BO, BI 181
bcctrl
20 M rlwimi RA, RS, SH, MB, ME 299
rlwimi.
21 M rlwinm RA, RS, SH, MB, ME 300
rlwinm.
23 M rlwnm RA, RS, RB, MB, ME 302
rlwnm.
24 D ori RA, RS, IM 295
25 D
oris RA, RS, IM 296
26 D
xori RA, RS, IM 350
27 D
xoris RA, RS, IM 351
28 D
andi. RA, RS, IM 172
29 D
andis. RA, RS, IM 173
31 0 X
cmp BF, 0, RA, RB 188
31 4 X
tw TO, RA, RB 341
31 8 (520) XO
subfc RT, RA, RB 328
subfc.
subfco
subfco.
31 10 (522) XO addc RT, RA, RB 162
addc.
addco
addco.
31 11 XO mulhwu RT, RA, RB 281
mulhwu.
31 19 X mfcr RT 263
31 20 X
lwarx RT, RA, RB 243
31 23 X
lwzx RT, RA, RB 248
31 24 X
slw RA, RS, RB 304
slw.
31 26 X cntlzw RA, RS 192
cntlzw.
31 28 X and RA, RS, RB 170
and.
31 32 X cmpl BF, 0, RA, RB 190
31 40 (552) XO
subf RT, RA, RB 327
subf.
subfo
subfo.
31 54 X dcbst RA, RB 205
31 55 X
lwzux RT, RA, RB 247
31 60 X
andc RA, RS, RB 171
andc.
Table A-2. PPC405 Instructions by Opcode (Continued)
Primary
Opcode
Secondary Opcode Form Mnemonic Operands Page
