D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
996
Format
config sim [[commander {group_name <groupname 64>} | candidate] | dp_interval <sec 30-
90> | hold_time <sec 100-255>]
Parameters
commander - Specify to transfer the role to the commander.
group_name - (Optional) Specify that if the user is the commander, the user can update the
name of group.
<groupname 64> - Enter the group name here. This name can be up to 64 characters long.
candidate - Specify to transfer the role to the candidate.
dp_interval - The time in seconds between discoveries.
<sec 30-90> - Enter the discovery time here in seconds. This value must be between 30 and
90 seconds.
hold_time - The time in seconds the device holds the discovery result.
<sec 100-255> - Enter the hold time here in seconds. This value must be between 100 and
255.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command..
Example
To transfer to commander:
DGS-3120-24TC:admin# config sim commander
Command: config sim commander
Success.
DGS-3120-24TC:admin#
To transfer to candidate:
DGS-3120-24TC:admin# config sim candidate
Command: config sim candidate
Success.
DGS-3120-24TC:admin#
To update name of group:
DGS-3120-24TC:admin# config sim commander group_name mygroup
Command: config sim commander group_name mygroup
Success.
DGS-3120-24TC:admin#
To change the time interval of discovery protocol:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
