D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1034
DGS-3120-24TC:admin# upload firmware_toTFTP 10.1.1.1 dest_file D:/firmware.had
src_file 100b70.had
Command: upload firmware_toTFTP 10.1.1.1 dest_file D:/firmware.had src_file
100b70.had
No such file.
Failure!
DGS-3120-24TC:admin#
To upload configuration from TFTP:
DGS-3120-24TC:admin#upload cfg_toTFTP 10.90.90.99 dest_file 111.cfg unit 1
src_file c:/config.cfg
Command: upload cfg_toTFTP 10.90.90.99 dest_file 111.cfg unit 1 src_file
c:/config.cfg
Connecting to server................... Done.
Upload configuration................... Done.
DGS-3120-24TC:admin#
In case that the designated file does not exist:
DGS-3120-24TC:admin#upload cfg_toTFTP 10.90.90.99 dest_file 111.cfg unit 1
src_file c:/config2.cfg
Command: upload cfg_toTFTP 10.90.90.99 dest_file 111.cfg unit 1 src_file
c:/config2.cfg
No such file.
Failure!
DGS-3120-24TC:admin#
To upload the master’s dangerous log:
DGS-3120-24TC:admin# upload attack_log_toTFTP 10.90.90.1 dest_file c:\alert.txt
Command: upload attack_log_toTFTP 10.90.90.1 dest_file c:\alert.txt
Success.
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
