D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
1033
up to 80 characters long.
log_toTFTP - Specify to upload a log file from device to TFTP server.
<ipaddr> - The IP address of the TFTP server.
<ipv6addr> - The IPv6 address of the TFTP server.
<domain_name 255> - Enter the domain name of the TFTP server.
dest_file - Used to identify the parameter “path_filename”.
<path_filename 64> - The pathname specifies the pathname on the TFTP server. It can
be a relative pathname or an absolute pathname. This name can be up to 64 characters
long.
attack_log_toTFTP – Specify that the attack log will be uploaded to the TFTP server.
<ipaddr> - The IP address of the TFTP server.
<ipv6addr> - The IPv6 address of the TFTP server.
<domain_name 255> - Enter the domain name of the TFTP server.
dest_file - Used to identify the parameter “path_filename”.
<path_filename 64> - Specify the path name on the TFTP server to hold the attack log.
This name can be up to 64 characters long.
unit - (Optional) The attack log messages on the specified unit will be uploaded to the
TFTP server. If it is not specified, it refers to the master unit.
<unit_id> - Enter the unit ID value. This value must be between 1 and 6.
firmware_toTFTP – Specify that the firmware file will be uploaded to the TFTP server.
<ipaddr> - The IP address of the TFTP server.
<ipv6addr> - The IPv6 address of the TFTP server.
<domain_name 255> - Enter the domain name of the TFTP server.
dest_file - Used to identify the parameter “path_filename”.
<path_filename 64> - The pathname specifies the pathname on the TFTP server. It
can be a relative pathname or an absolute pathname. This name can be up to 64
characters long.
unit - (Optional) Specify which unit on the stacking system. If it is not specified, it refers to
the master unit.
<unit_id> - Enter the unit ID value. This value must be between 1 and 6.
src_file - (Optional) Used to identify the parameter “path_filename”.
<pathname> - The pathname specifies an absolute pathname on the device file
system. If pathname is not specified, it refers to the boot_up image. This name can
be up to 64 characters long.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To upload firmware from a file system device to a TFTP server:
DGS-3120-24TC:admin# upload firmware_toTFTP 10.1.1.1 dest_file D:/firmware.had
src_file 100b70.had
Command: upload firmware_toTFTP 10.1.1.1 dest_file D:/firmware.had src_file
100b70.had
Connecting to server................... Done.
Upload firmware........................ Done.
DGS-3120-24TC:admin#
In case that the designated file does not exist:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
